The system is made of durable galvanized steel, usually it uses gypsum boards as surface material. It is widely used in offices and residential building for its easiness of installation. Compared with wooden board, gypsum boards can provide a safer and fire-resistive wall. And, compared with bulky brick wall, it can greatly reduce the weight of building. Besides, thermal and acoustic insulation product may be filled in partition frame to create a safe and quiet environment.
The system is made of durable galvanized steel, usually it uses gypsum boards & calcium silicate board as surface materials.
Vertically fit the stud into the track. The maximum distance between studs is 610 m/m. Gypsum boards may be screwed or nailed on the both flanges. Both flanges have slide-proof points to prevent projecting screws from sliding while fixing the gypsum board.
metal stud
metal track
Galvanzed steel metal stud for drywall partition system:
| Width | Height | length | thickness |
| 50 | 35 | 2700/3000mm or any length | 0.30-1.20mm |
| 65 | 35 | 2700/3000mm or any length | 0.30-1.20mm |
| 70 | 35 | 2700/3000mm or any length | 0.30-1.20mm |
| 75 | 35 | 2700/3000mm or any length | 0.30-1.20mm |
| 90 | 35 | 2700/3000mm or any length | 0.30-1.20mm |
| 98 | 35 | 2700/3000mm or any length | 0.30-1.20mm |
| 146 | 35 | 2700/3000mm or any length | 0.30-1.20mm |
Galvanzed steel metal track for drywall partition system:
| Width | Height | length | thickness |
| 52 | 35 | 2700/3000mm or any length | 0.30-1.20mm |
| 67 | 35 | 2700/3000mm or any length | 0.30-1.20mm |
| 72 | 35 | 2700/3000mm or any length | 0.30-1.20mm |
| 77 | 35 | 2700/3000mm or any length | 0.30-1.20mm |
| 92 | 35 | 2700/3000mm or any length | 0.30-1.20mm |
| 100 | 35 | 2700/3000mm or any length | 0.30-1.20mm |
| 148 | 35 | 2700/3000mm or any length | 0.30-1.20mm |
All the width/height/length/thickness can be customized.
stud packing: 10pcs/bdl
track packing: 10pcs/bdl
