Sourcing 14 gauge 6 inch 92mm metal steel wall studs at true wholesale prices for your next commercial drywall project? This guide breaks down steel wall studs for sale, ASTM C955/C754 compliance, gauge-by-gauge cost benchmarks, and import logistics — direct from an ISO-certified Chinese manufacturer with a 200M+ RMB annual output.
📥 Get Wholesale Quote in 24 Hours →⚡ Free sample available · OEM/ODM accepted · MOQ from 1×40'HQ
The reality of 2026 global steel sourcing: unless you are directly integrated with a mill or a factory-owned export arm, you are likely paying 25–40% above true wholesale for 6-inch metal studs. Here are the top hidden costs we hear from procurement managers every week:
For 14 gauge metal studs price, traders routinely add US$0.40–0.80 per piece on top of factory cost. On a 10,000-piece order, that’s $8,000 in pure margin leakage — with zero added value in quality or lead time.
Some suppliers ship 0.85mm instead of 0.068” (14 ga) knowing the spec gap is hard for the buyer to verify at port. Result: reduced load-bearing capacity, failed fire-rating tests, and expensive on-site rework.
Since 2020, container freight from China to the US West Coast has swung from $1,500 to over $8,000. Many buyers fail to account for steel studs' metre-weight × volume ratio, overpaying on volumetric weight.
According to the World Steel Association trade report, international tariff disputes directly impact the cost of drywall steel profiles. When tariffs on galvanized steel coil rise in North America, buyers must pivot to alternative sourcing regions or absorb surcharges.
Traditional supply chains to Europe/North America average 60–75 days from PO to job site. Without a factory-owned production plan, delays cascade; one missed window can shut down a framing crew for weeks.
Need special web perforations, custom slotted lengths, or pre-punched service holes? Most trading companies cannot modify roll-forming tooling. We hold 1 invention patent + 13 utility patents — custom profiles are our core strength.
Bottom line: You are paying higher 6 inch metal studs price because someone in the middle is profiting from your lack of supply-chain integration. → Cut the middleman out now.
Wen’an Jinkai Building Materials Co., Ltd. operates a fully integrated production line for drywall steel profiles, including the Canada-US system, Australian, and Middle East furring systems. We manufacture the 14 gauge 6 inch 92mm metal steel wall stud with precision roll-forming, certified steel coil, and QC inspection at every stage.
| Product Name | Steel Wall Stud (Drywall Framing Stud) |
| Nominal Size | 6 inch (152.4 mm) · 92 mm (3.625") |
| Gauge | 14 Gauge (0.068" / 1.73 mm base steel thickness) |
| Material Grade | ASTM A653 / S550GD+Z · G40 / G60 / G90 Z275 coating |
| Web Width | 92 mm (3.625") |
| Flange Width | 38 mm (1.5") or custom |
| Length | 8' / 10' / 12' (custom 2438/3048/3658 mm) |
| Web Perforations | Pre-punched service holes (default Ø 1" @ 24" o.c.) |
| Coating | Hot-dip Galvanized · AZ150 (Galvalume) available |
| Standards | ASTM C955 · C754 · JIS G3350 · AS/NZS 3623 |
| Yield Strength | ≥ 550 MPa (S550 class) |
Load-bearing capacity for curtain wall & mid-rise steel-framed partitions
Fire-rated assemblies — 1-2 hour UL listings with proper drywall lining
Acoustic STC 55+ when paired with resilient channels
Compatible with Canada-US Drywall System tracks & accessories
Roll-forming line at Wen'an Jinkai factory
Micro-CTA: Need a detailed 92mm steel stud price quote with your exact coating and length? 👉 Request Data Sheet
The 6 metal stud price varies significantly with gauge thickness. Below are typical wholesale price ranges for 6" 92 mm studs in standard G60 galvanized coating, 10-foot lengths, based on Q1 2026 steel coil pricing (order volume ≥ 1×20' container). Prices are indicative; call or email for a live quote.
| Gauge | Base Steel Thickness | Weight (kg/10') | Wholesale Price/PC (FOB) | Typical Use |
|---|---|---|---|---|
| 20 Gauge | 0.033" (0.85 mm) | 2.6 kg | $1.85 – $2.20 | Interior non-load-bearing partitions |
| 18 Gauge | 0.043" (1.09 mm) | 3.3 kg | $2.40 – $2.80 | Standard commercial walls, shaft walls |
| 16 Gauge | 0.053" (1.35 mm) | 4.0 kg | $2.90 – $3.40 | Load-bearing, high-traffic areas, balcony rails |
| 14 Gauge ⭐ | 0.068" (1.73 mm) | 5.1 kg | $3.60 – $4.20 | Heavy-duty curtain wall, seismic / wind zones |
⚠️ Note: The 6 16 gauge metal studs price and 6 18 gauge metal studs price above reflect mid-2026 market indices. For a live 14 gauge metal studs price or 6 20 gauge metal studs price, request a formal quotation.
80% of buyers choose 14 or 16 gauge for curtain wall applications
Up to 12% steel saving with optimized web perforations
1×40'HQ ≈ 18,000 pcs of 10' 14 gauge studs
When comparing quotations from Chinese factories, never compare sticker prices alone. The total steel wall studs wholesale price is a function of five variables:
| Factor | Impact on Price |
|---|---|
| 1. Steel Coil Index | Hot-dip galvanized coil is 60–65% of the cost. The global coil price (Argus / Platts) moves weekly; lock pricing with a 7-day validity contract. |
| 2. Coating Weight | G40 (Z120) → G60 (Z180) → G90 (Z275) adds 3–8% price. Coastal environments require G90 per NACE corrosion research to prevent rust bleed and structural failure. |
| 3. Length & Perforation | Custom lengths (e.g., 11' 4") and pre-punched slots increase yield loss; expect a +2–4% surcharge. |
| 4. Order Volume | 1×20' container vs 5×40'HQ: volume pricing can drop the 6 inch metal studs price by 7–10%. |
| 5. Logistics & Delivery | FOB, CIF, or DDP terms shift cost responsibility. The World Steel Association report notes tariff volatility is pushing buyers to bulk order Ultra-Light grids that minimize steel weight per linear foot while maintaining strength — ask us about these options. |
*Reference: Global Trade Report: Import Tariffs on Galvanized Steel Coil (worldsteel.org)
"In 2026, most buyers who get burned by 'too good to be true' pricing are seeing G40 coating substituted for G60, or 20-gauge steel labeled as 14-gauge at the edges. Always demand a mill test certificate and a third-party SGS inspection at the factory. It costs US$200–300 per shipment, but it protects a US$50,000+ order."
Per the Japanese Industrial Standards review at jisc.go.jp, adopting JIS tolerances in roll-forming improves the snap-fit connections of ceiling & stud systems, reducing loose joints in the field by up to 30%. Our line is JIS-compliant on request.
You need confidence in the steel behind your walls. Our 14 gauge 6 inch 92 mm metal steel wall studs and entire drywall product family are backed by the following:
ISO 9001:2008
Quality Management
CE Marking
EU Construction Products
UL-Listed
Fire-Rated Assemblies
ASTM C955 / C754
Structural Compliance
SGS Verified
Third-Party Inspection
NIST forensic study on T-Bar grid failures (nist.gov): "FUT style connections eliminate the human error factor in cross-tee disengagement" — our FUT connection slots are engineered to spec. We apply this engineering control to our ceiling grids and stud web tabs for wall frames.
AWCI seismic analysis (awci.org): Australian drywall systems show superior seismic performance in South America — our Australian line follows AS/NZS 3623.
ScienceDirect fire study (sciencedirect.com): Optimized slot perforations in stud webs reduce thermal conductivity by up to 15% — our eco-perforated profiles improve fire resistance without sacrificing strength.
NACE coastal corrosion study (nace.org): Steel furring channels within 5 km of the sea require G90 or stainless grades; we supply AZ150/G90 as standard upgrade options.
Our 14 gauge 6 in 92mm steel wall studs for sale are installed in a wide range of environments. Here's where this heavy-gauge profile delivers the most value:
Bracket loads from aluminum composite panels or stone veneer require 14 ga. structural studs. Case: a 22-story commercial tower in Jakarta used our 92 mm 14 ga studs at 300 mm o.c. to support exterior spandrel steel — saving 17% compared to their previous C-Channel structural system.
UL-listed 2-hour fire partitions require precise gauge, coating, and screw spacing. A Melbourne hospital project replaced imported US studs with our Australian drywall system equivalent, cutting landed cost by 31% while meeting AS 1530 fire standards.
Per AWCI research, stud geometry directly affects acoustic isolation. Our 92 mm deep web provides greater air gap and accommodates double-layer insulation. A sound studio in Dubai achieved STC 58 using our 14 ga studs + resilient channels.
For projects within 5 km of the sea, our G90 / AZ150 coating option prevents rust bleed. The NACE study highlights weld-point corrosion; we hot-dip after punching to protect edges. A resort project in Cancún specified our G90 studs for all interior partition walls.
Situation: A Philippines pre-cast contractor needed 40,000 pieces of 92mm 14-gauge studs for a 14-story residential project.
Our solution: Factory-owned roll-forming lines + pre-booked shipping slot.
Result: Production 12 days, sailing 18 days, unloading 3 days — total landed in 35 days, with 0 non-conformity at QC. The contractor re-ordered 2 more containers within the same quarter.
We are not a trading company. We are a state-certified High-Tech Enterprise with our own production campus in Langfang, Hebei — 60 km south of Beijing — operating with nine-figure RMB annual output.
Representative brand logos — used with permission or as publicly listed project references.
"We switched to Jinkai for our 6 inch 16 gauge metal studs after a bad batch from Vietnam. The thickness is consistent — I measured 1.34-1.36 mm across 50 random samples. Their QC is real, not paper."
"Ordered 1,200 pieces of 14 gauge 92mm studs for a curtain wall retrofit in Brisbane. The 14 gauge metal studs price came in 22% below our previous supplier in the US. Delivery was 5 days ahead of schedule."
"We used Jinkai's studs for a Hilton renovation project. G90 coating held up perfectly in our humid coastal climate. Their team helped us switch from the South American system to the Australian profile — zero rework."
Ready to become our next success story? Let's talk numbers
MOQ is 1×20' container (approx. 8,000–10,000 pcs of 10' studs, depending on gauge and packaging). For first-time customers, we can discuss a mixed-container trial order combining ceiling T-bar and drywall profiles to test the ground. Free samples are available for freight-cost-only basis.
Yes. Our roll-forming lines can cut to any length from 300 mm to 6000 mm with a tolerance of ±1 mm. Custom lengths like 9'4" or 11'6" require a short production setup but do not affect the 92mm steel stud price significantly (+1–2%).
Work with a factory that releases its mill test certificate and offers third-party inspection (SGS/BV). Always request an FOB vs CIF comparison; sometimes a supplier's high FOB price is offset by very competitive CIF terms because they control the freight booking. Use a live steel coil index to validate the quote.
Production for a 1×40'HQ container is typically 7–15 days after bank confirmation/deposit. Sea freight: 18–25 days to Los Angeles / Long Beach, 22–30 days to Rotterdam, 15–20 days to Sydney (subject to port congestion). We book slots with COSCO/MSC/CMA pragmatically and provide ETD/ETA alerts.
For first orders: T/T (30% deposit, 70% against copy of Bill of Lading) or L/C at sight. For repeat customers: O/A 30–60 days may be available after credit assessment. We do not accept PayPal for container orders due to transaction limits.
Yes. Our studs are manufactured to ASTM C955 for US projects and EN 14195 for European markets. We also produce to JIS G3350 and AS/NZS 3623 standards. For fire-rated assemblies, our profiles are compatible with UL/CE-design systems. We provide a declaration of performance (DoP) on request.
Absolutely. Based on AWCI's comparative analysis, South American systems (Montantes y Soleras) prioritize axial load for concrete-encased structures, while North American (Canada-US) systems use wood/steel backup framing. Our engineers help you select the right profile series — that's why we manufacture all five major international systems under one roof.
Common methods: steel strapping bundles (100–200 pcs/bundle), wrapped in kraft paper or PP woven fabric, with wooden pallet or slip-sheet base. For 14 gauge heavy studs, we use double-layer corner protectors and apply an anti-rust VCI paper layer when humidity is a concern. Additional export wooden crates are available for LCL breakbulk shipments.
We reply within hours, not days. Here are recent chat interactions with buyers who requested the 14 gauge metal studs price and wholesale terms.
*Screenshots shared with client consent for marketing purposes.
Send us your spec: gauge, length, quantity, coating, and destination port. Receive a fully itemed quotation within 24 hours — with FOB / CIF / DDP options.
🔒 Your inquiry is confidential and protected under our privacy policy. We never share your data with third parties.
Brank Wong — Senior Export Manager at Wen'an Jinkai Building Materials Co., Ltd., with 12+ years in cold-formed steel manufacturing and international drywall system supply. Brank has personally overseen the export of over 5,000 containers of ceiling & drywall profiles across Australia, Southeast Asia, the Middle East, and the Americas. He holds a B.Eng. in Materials Engineering and is a member of the China Building Decoration Materials Association.
